4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB

  • 1
  • 2
  • 3

Brand Name : GC

Model Number : GC-UV-A

Certification : ISO

Place of Origin : China

MOQ : 1 Set

Price : Negotiated

Payment Terms : TT

Supply Ability : 100 Sets

Delivery Time : In stock

Packaging Details : Wooden package

Model NO. : GC-UV-A

Trademark : GC

Origin : China

Package Size : 146.00cm * 75.00cm * 170.00cm

Package Gross Weight : 200.000kg

Customization : Available

Transport Package : Wooden Packaging

Specification : 45*117*50cm

Contact Now

Product Description

UV Aging Test Chamber

4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB

Product Introduction


The test equipment simulates the damage caused by the sun's ultraviolet light, and the weather resistance test is carried out on the material by exposing the tested material to light under controlled high temperature. It uses ultraviolet lamps to simulate the radiation of sunlight, and simulates dew and rain through condensation and water spraying. In just a few days or weeks, the ultraviolet irradiation equipment can reproduce the effects of outdoors that take months or even years. Damage that takes time to occur, including fading, color change, tarnish, chalking, cracking, cracks, wrinkling, blistering, embrittlement, strength reduction, oxidation, etc. The test results can be used to select new materials and improve existing There is a change in the material, or the formulation of the evaluation material.

Test Standards

1. GB/T14552-2008 "National Standard of the People's Republic of China--Plastic, Coating, Rubber Materials for Mechanical Industry Products-Artificial Climate Accelerated Test Method" a, Fluorescence UV/condensation test method.
2. GB/T16422.3-1997 GB/T16585-96 related analysis methods.
3. GB/T16585-1996 "National Standard of the People's Republic of China - Test Method for Artificial Weathering of Vulcanized Rubber (Fluorescent UV Lamp)".
4. GB/T16422.3-1997 "Plastic laboratory light source exposure test method" and other corresponding standard items design and manufacture standards.
5. Comply with international testing standards: ASTM D4329, ISO 4892-3, ISO 11507, SAE J2020 and other current UV aging test standards.

4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB
4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB

Model: GC-UV-A
Product Application

4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB

Model GC-UV-B
Dimensions of the working chamber (cm) 45*117*50CM
Boundary dimension(cm) 70*135*145CM
Power 4.0(KW)
Performance index

Temperature range Rt+10ºC~70ºC
Humidity range ≥95%R.H
Distance between lamps 35mm
Distance between sample and lamp 50mm
Support quantity of the sample Length 300mm* width 75mm, about 48 pieces
Ultraviolet wavelengths 290nm~400nm UV-A340,UV-B313,UV-C351( instructions at time of order )
Lamp power 40W
Control system

Controllor touch screen microcomputer controller
Illumination heating system Fully independent system, nickel-chromium alloy electric heating heater
Condensation humidification system All stainless steel shallow surface evaporative humidifier
Blackboard temperature Bimetal blackboard thermometer
Water supply system Automatic control for humidification and water supply
Exposure method Exposure to moisture condensation, exposure to light radiation
Safety protection Leakage, short circuit, over temperature, water shortage, over current protection
Detailed Photos

4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB4 Kw Environmental Testing Chamber UV Testing Machine Lamp With UVA UVB
